Plunger – Type Pumps / Engine Driven Type Pump Units

SUGINO PUMP SERIES ENGINE DRIVEN PUMP UNIT
Engine driven pump units are plunger type pump used for outdoor work like civil engineering and construction sites where no electrical power supply is available.
JPHP
All-round-type ultrahigh-pressure pump units for multiple purposes from cleaning to chipping.
There are many variations, allowing you to choose the optimal model according to your needs.
-Max.Discharge Pressure : 280MPa
-Max.Discharge Rate : 120L/min
-Applications : Plant facility cleaning, peeling, chipping, etc
-4 ton truck mountable
-The pressure and the flow rate of stand-alone JPHP pumps can be changed to those of another JPHP series model by replacing the head and the pressure regulator.

JPHP / HI-JET3000GT|JPHP
An eco-friendly, high-output engine is adopted to allow this high-end ultrahigh-pressure pump unit to have a large flow rate and be environmentally conscious at the same time.
This type of pump unit is clean and powerful and will demonstrate its outstanding performance in chipping works of concrete structures.
Max.Discharge Pressure : 280MPa
Max.Discharge Rate : 45L/min
Applications : Peeling, chipping, etc
Sound proof
4 ton truck mountable
Automatic operation : This feature controls the rotation speed of the engine automatically to achievethe chosen pressure setting.

GP11 / HI-JET3000ST
Lightweight and compact pump units that can be mounted on a 3-ton truck.
Best suited for a narrow space such as asbestos removal on demolition site and white line peeling on roads.
Max.Discharge Pressure : 245MPa
Max.Discharge Rate : 28L/min
Applications : Peeling, chipping, etc
Sound proof
3 ton truck mountable
Automatic operation : This feature controls the rotation speed of the engine automatically to achievethe chosen pressure setting.

JPHP / HI-JET3000DT
Ultrahigh-pressure, large flow rate pump units equipped with two pumps.
The most effective chipping work to concrete structure can be realized.
Max.Discharge Pressure : 245MPa
Max.Discharge Rate : 78L/min
Applications : Chipping, etc
Simple Sound proof
Ultra-high pressure and large flow rate specifications
Automatic operation : This feature controls the rotation speed of the engine automatically to achievethe chosen pressure setting.

JPKP / HI-JET2000, JPHP / HI-JET3000
The most versatile model for water jet blasting operations based on a superior balance between pressure and flow rate for peeling, as well as the chipping and cutting of concrete.
This model is lightweight and soundproof and can be used in urban areas without causing noise issues.
Max.Discharge Pressure : 300MPa
Max.Discharge Rate : 27L/min
Applications : Peeling, chipping, etc
Sound proof
4 ton truck mountable
Automatic operation : This feature controls the rotation speed of the engine automatically to achievethe chosen pressure setting.

GP11
Compact pump units equipped with an engine that is direct-coupled to a pump with built-in gears.
Max.Discharge Pressure : 33MPa
Max.Discharge Rate : 220L/min
Applications : Plant facility cleaning, water and sewer cleaning, etc
4 ton truck mountable

JPKP
The most lightweight engine-driven pump unit.
Max.Discharge Pressure : 170MPa
Max.Discharge Rate : 50L/min
Applications : Plant facility cleaning, etc
3 ton truck mountable

JCP500
High pressure, large flow rate pump units equipped with a five-plunger pump.
Max.Discharge Pressure : 150MPa
Max.Discharge Rate : 330L/min
Applications : Strong cleaning, chipping, etc
High pressure High flow rate spec.

JCP170
Large flow rate pump units that can be used for a wide variety of applications such as the cleaning of large diameter or long length tubes, or the chipping of deteriorated concrete.
Max.Discharge Pressure : 82MPa
Max.Discharge Rate : 200L/min
Applications : Plant facility cleaning, large-diameter tube cleaning, etc
High / Low Pressure Switchable Type ;
It is possible to switch between high pressure and low pressure with a large flow rate by a single handle operation according to the application.

GP11
Lightweight and compact pump units that can be mounted on a 3-ton truck.
Max.Discharge Pressure : 77MPa
Max.Discharge Rate : 180L/min
Applications : Plant facility cleaning, water and sewer cleaning, etc
3 ton truck mountable
High / Low Pressure Switchable Type :
It is possible to switch between high pressure and low pressure with a large flow rate by a single handle operation according to the application.
