SELFEEDER MECHATRIC MS7M : Servo Feed Drilling Unit

SELFEEDER MECHATRIC MS7M

High output servo feed type drilling unit is capable of drilling max of φ28 with steel !

High-power model which has a 3.7kW spindle motor and 7,800N thrust.
This unit can perform facing, end-milling and max of 28mm diameter drilling in steel.



Max. drilling size  … φ28(Steel)/ φ40(Aluminum)

Model

Specifications

Feed shaft motor: 2.7 kW  AC servo motor

Notes:

  • To select your model, refer to the workpiece configurations, material, cutting properties, diameter of the hole, and rotation speed.(cutting speed)

  • The drilling capacity shown above corresponds to a depth equivalent to the drill diameter times two.

  • The power voltage of the feed controller and main spindle motor is a 3-phase 200V AC±10%, 50/60Hz.

  • In the case of a servo motor with a holding brake (optional), add “B” to the end of the model number.

  • AL : Aluminum(ADC12) , FC : Cast iron(FC200) , ST : Steel(S45C)

Dimensions
